NIGHT VISION GOGGLES

---

Specifications:

• Field of View: 40°
• Magnification: 1x
• System Resolution: 1.3cy/mR minimum
• Diopter Adjustment: -6 to +2
• IPD: 52mm – 72mm
• Vertical Adjustment: 25mm
• Fore/Aft Adjustment: 27mm
• Collimation: Convergence 1.0°, Divergence 0.33°
• Tilt Adjustment: 10° Minimum
• Focus Range: 25cm to ∞
• Battery Type/Life: AA 1.5VDC/80 Hours Battery Pack Loaded
• Weight: Binocular 534g (1.17 lbs), Mount 150g (0.33 lbs)
• Environmental: ML-STD-810H

Specifications:

• Field of View: 40°
• Image Intensifier Tube: High-Performance Gen 3 L3 or Elbit Image Tubes
• Magnification: 1x [3x Optional]
• Lens System: 27mm, F/1.3
• Focus Range: 0.25m to ∞
• Eye Relief: 17mm
• Diopter Adjustment: -6 to +2
• Led Indicators: Low Battery; IR on; Excessive Light Conditions
• Manual Gain Control: Yes
• Bright Light Cut-Off: Yes
• Automatic Shut-Off System: Yes
• Infrared Illuminator: Yes; Two Power Levels
• Battery Type: One CR123A (3v) or AA (1.5V)
• Battery Life (Operating): Up to 20 Hours at 20°C (Up to 80 Hours with Optional Battery Pack)
• Operating Temperature Range: -40°C to +50°C (-40°F to +122°F)
• Storage Temperature Range: -50°C to +50°C (-58°F to +122°F)
• Weight: 615g (1.35 lbs)
• Overall Dimensions: 4.4 x 4.6 x2.9 in

Specifications:

• Field of View: 40°
• Image Intensifier Tube: High-Performance Gen 3 L3 or Elbit Image Tubes
• Magnification: 1x
• Inter-pupillary Adjustment: 51mm to 73mm
• Focus Range: 0.25m to ∞
• Eye Relief: 25mm
• Diopter Adjustment: -6 to +2
• Led Indicators: Low Battery; IR on; Excessive Light Conditions
• Manual Gain Control: Yes
• Bright Light Cut-Off: Yes
• Automatic Shut-Off System: Yes
• Infrared Illuminator: Yes
• Battery Type: One AA (1.5V)
• Battery Life (Operating): Over 16 Hours at 20°C with Lithium Battery
• Operating Temperature Range: -40°C to +50°C (-40°F to +122°F)
• Storage Temperature Range: -50°C to +50°C (-58°F to +122°F)
• Weight: 555g (1.22lbs) (without battery)
• Overall Dimensions: 4.7 x 4.6 x2.8 in

Specifications:

• Field of View: 40°
• Magnification: 1x
• Power Source: 1 CR123
• Diopter Adjustment: -6 to +2
• IR Illuminator: Built-In
• Inter-pupillary Adjustment: 47mm to 80mm+
• Diopter Adjustment: -6 to +2
• Eye Relief: 25mm
• Water Resistance: Submersible to 66ft
• Focus Range: 25cm to ∞
• IR & Low Battery Indicators: Yes
• Intensifier Tubes: High-Performance Gen 3 L3 or Elbit Image Tubes
• Optics: Mil-Spec ANVIS
• Weight: Binocular 578g (1.27 lbs) with Mil-Spec Optics & L3 Image Tubes (No Battery)
• Battery Life (Operating): Approximately 16 Hours
• Warranty: 5-Years

Specifications:

• Field of View: 40°
• Magnification: 1x
• Focus Range: 25cm to ∞
• Focal Length: 27mm (1")
• Diopter Adjustment: +2 to -6
• Image Tube: High-Performance Gen 3 L3 or Elbit White Phosphor Image Tubes
• Power Supply: 1xCR123A (3V) Lithium Battery
• Operating Time: 24 Hours or 80 Hours with Optional LEMO Extended Run Battery Pack
• Weight Without Battery: 395g (0.87 lbs)
• Dimensions: 4.13 x 4.33 x 2.95 in
• Environmental: MIL-STD 810G IP68
• Auto Power Off: Yes
• Manual Gain Control: No
• IR Illuminator: No
• Low Power Indicator: Yes
• Standard Content: Soft Case, Operation Manual, Battery, Cleaning Kit

Specifications:

• Field of View: 40°
• Magnification: 1x
• Focus Range: 25cm to ∞
• Focal Length: 27mm (1")
• Diopter Adjustment: +2 to -6
• Image Tube: High-Performance Gen 3 L3 or Elbit White Phosphor Image Tubes
• Power Supply: 1xCR123A (3V) Lithium Battery
• Operating Time: 24 Hours or 80 Hours with Optional LEMO Extended Run Battery Pack
• Weight Without Battery: 395g (0.87 lbs)
• Dimensions: 4.13 x 4.33 x 2.95 in
• Environmental: MIL-STD 810G IP68
• Auto Power Off: Yes
• Manual Gain Control: Yes
• IR Illuminator: Yes
• Low Power Indicator: Yes
• Standard Content: Soft Case, Operation Manual, Battery, Cleaning Kit

Specifications:

• Field of View: 40°
• Magnification: 1x [Optional 3x and 5x]
• Focus Range: 25cm to ∞
• Diopter Adjustment: -6 to +4
• Lens System: 26mm; F/1.2
• Image Intensifier Tube: High-Performance Gen 3 Image Tubes
• Led Indicators: Low Battery; IR On; Excessive Light Conditions
• Operating Temperature Range: -51°C to +49°C (-60°F to 120°F)
• Storage Temperature Range: -51°C to +85°C (-60°F to 185°F)
• Battery Type: One AA Alkaline
• Battery Life [Operating]: Up to 50 Hours at 20°C
• Manual Gain Control: Yes
• Bright Light Cut-Off: Yes
• Infrared Illuminator: Yes
• Weight: 0.7 lbs
• Dimensions: 4.4 x 2.4 x 2.4 in
• Package Includes: Head Mount Assembly, Brow Pad, Eye Cup, Helmet/ Head Mount Adapter, System Soft Carrying Case, Daylight Filter, Shoulder Strap, Lens Paper, Diopter Lens Cap, Sacrificial Window, Demist Shields, Operator’s Manual, and Battery

Specifications:

• Field of View: 40°
• Magnification: 1x [Optional 3x and 5x]
• Focus Range: 25cm to ∞
• Diopter Adjustment: -6 to +2
• Lens System: 19mm; F/1.26
• Image Intensifier Tube: Gen 2+ or Gen 3
• Led Indicators: Low Battery; IR On; Excessive Light Conditions
• Operating Temperature Range: -51°C to +49°C (-60°F to 120°F)
• Storage Temperature Range: -51°C to +85°C (-60°F to 185°F)
• Battery Type: One CR123 or AA Alkaline
• Battery Life [Operating]: Up to 80 Hours at 20°C (CR123)
• Manual Gain Control: Yes
• Bright Light Cut-Off: Yes
• Infrared Illuminator: Yes
• Weight: 0.59 lbs
• Dimensions: 4.5 x 2.5 x 2.75 in
• Package Includes: Head Mount Assembly, Brow Pad, Eye Cup, Helmet/ Head Mount Adapter, System Soft Carrying Case, Daylight Filter, Shoulder Strap, Lens Paper, Diopter Lens Cap, Sacrificial Window, Demist Shields, Operator’s Manual, and Battery

Overview:

• Field of View: 9°
• Magnification: Unity 1x
• Image Intensifier Tube: Gen 3 High-Performance Thin-Filmed or Filmless Auto-Gated IIT, L3 or Elbit. FOM Restricted 1600,1800, and 2000 FOM Image Tubes Options are also available for foreign requirements.
• Lens System: 108mm; F/1.54
• Focus Range: 10m to ∞
• Exit Pupil: 40mm

User Interface:

• Operation Switch: On/Off/Standby Mode
• Brightness Adjustment Knob: Variable Gain Control
• Remote Control Button: Activates/Deactivates the Clip-On in Standby Mode
• Focus Knob: Focuses the Objective Lens
• Battery Indicator: Battery Status Indication (In FOV)

System Specifications:

• Boresight Characteristics: Accuracy (0.23mrad/lp), Retention (0.19mrad/lp), Repeatability (0.16mrad/lp)
• Manual Gain Control: Yes
• Bright Light Cut-Off: Yes
• Automatic Shut-Off System: Yes
• Low Battery Indicator: Yes
• Infrared Illuminator: IR850-XLR Detectable Extra Long-Range IR Illuminator
• Remote Control: Wireless

Power:

• Battery Type: Single AA (1.5V) or CR123A (3V)
• Battery Life (Operating): Up to 45 Hours

Environmental:

• Operating Temperature Range: -40°C to +50°C (-40°F to +122°F)
• Storage Temperature Range: -50°C to +50°C (-58°F to +122°F)

Physical:

• Weight: 2 lbs
• Size (With Mount): 9.25 x 3.8 x 3.14 in
• Weapon Mount Type: Picatinny, MIL-STD 1913, or Weaver Rails
• Height of The Scope Axis Above Rail: 1.57 in
• Color (Housing): Black

Overview:

• Field of View: 12°
• Magnification: Unity 1x
• Image Intensifier Tube: Gen 3 High-Performance Thin-Filmed or Filmless Auto-Gated IIT, L3 or Elbit. FOM Restricted 1600,1800, and 2000 FOM Image Tubes Options are also available for foreign requirements.
• Lens System: 80mm; F/1.44
• Focus Range: 10m to ∞
• Exit Pupil: 21mm

User Interface:

• Operation Switch: On/Off/Standby Mode
• Brightness Adjustment Knob: Variable Gain Control
• Remote Control Button: Activates/Deactivates the Clip-On in Standby Mode
• Focus Knob: Focuses the Objective Lens
• Battery Indicator: Battery Status Indication

System Specifications:

• Boresight Characteristics: Accuracy (Factory Aligned to 1/2 MOA or Better), Retention (Permanent to Within 1 MOA or Better), Repeatability (Within 1/2 MOA)
• Manual Gain Control: Yes
• Bright Light Cut-Off: Yes
• Automatic Shut-Off System: Yes
• Low Battery Indicator: Yes
• Infrared Illuminator: IR850-XLR Detectable Extra Long-Range IR Illuminator
• Remote Control: Wireless

Power:

• Battery Type: CR123 Lithium 3V (1), AA Alkaline 1.5V (1), any AA or CR123 type rechargeable batteries with voltage from 1.2V to 3.2V (1)
• Battery Life (Operating): Up to 60 Hours

Environmental:

• Operating Temperature Range: -40°C to +50°C (-40°F to +122°F)
• Storage Temperature Range: -50°C to +50°C (-58°F to +122°F)

Physical:

• Weight: 1.56 lbs
• Weight* (Including Mount): 1.67 lbs
• Size (With Mount): 5.9 x 3.9 x 3.2 in
• Weapon Mount Type: Picatinny, MIL-STD 1913, or Weaver Rails
• Height of The Scope Axis Above Rail: 1.5 in
• Color (Housing): Black

Overview:

• Field of View: 22°
• Magnification: Unity 1x
• Image Intensifier Tube: Gen 3 High-Performance Thin-Filmed or Filmless Auto-Gated IIT, L3 or Elbit. FOM Restricted 1600,1800, and 2000 FOM Image Tubes Options are also available for foreign requirements.
• Lens System: 38mm; F/1.25
• Focus Range: 20m to ∞
• Exit Pupil: 27.5mm

User Interface:

• Operation Switch: On/Off/Standby Mode
• Brightness Adjustment Knob: Variable Gain Control
• Remote Control Button: Activates/Deactivates the Clip-On in Standby Mode
• Battery Indicator: Battery Status Indication (In FOV)

System Specifications:

• Boresight Characteristics: Accuracy (Factory Aligned to 2 MOA or Better), Retention (Permanent to Within 4 MOA or Better), Repeatability (Within 2 MOA)
• Manual Gain Control: Yes
• Bright Light Cut-Off: Yes
• Automatic Shut-Off System: Yes
• Low Battery Indicator: Yes
• Infrared Illuminator: IR850-XLR Detectable Extra Long-Range IR Illuminator
• Remote Control: Wireless

Power:

• Battery Type: CR123 Lithium 3V (1), AA Alkaline 1.5V (1), any AA or CR123 type rechargeable batteries with voltage from 1.2V to 3.2V (1)
• Battery Life (Operating): Up to 60 Hours

Environmental:

• Operating Temperature Range: -40°C to +50°C (-40°F to +122°F)
• Storage Temperature Range: -50°C to +50°C (-58°F to +122°F)

Physical:

• Weight: 0.95 lbs
• Weight* (Including Mount and Light Suppressor): 1.06 lbs
• Size (Without Mount): 4.9 x 2.7 x 2.2 in
• Weapon Mount Type: Picatinny, MIL-STD 1913, or Weaver Rails
• Height of The Scope Axis Above Rail: 1.65 in
• Color (Housing): Black
